P/N, description, qty needed.
|
from |
to |
GBP |
| 1 |
LPF100790 - Pump assembly-engine oil
superceeded by
LPF000030
|
|
|
97,55 |
| 1 |
LPF000030 - Pump assembly-engine oil
|
|
|
238,55 |
| 2 |
LQX100040 - Seal-crankshaft front oil
|
|
|
22,90 |
| 3 |
LQX100030 - Kit-oil pump repair
|
|
|
10,39 |
| 4 |
LVG100330 - Gasket-cylinder block oil
pump
|
|
|
2,39 |
| 5 |
PYG10007 - Bolt-flanged head
|
|
|
0,31 |
| 6 |
LYP10003 - Screw-flanged head
|
|
|
0,32 |
| 7 |
LPX100360 - Head
assembly-engine oil filter
superceeded since later engines
M10x1 check oil temperature sensor thread before you buy
M12x1.5 or M10x
|
|
18K4FJ31 646501
or
18K4FJ32 646201 |
|
| 7 |
LPX100540 - Head assembly-engine oil
filter
Except: VVC |
|
app.
YD511058 |
18,99 |
| 7 |
LPX000160 - Head assembly-engine oil
filter
VVC - from YD 511059 on |
VVC YD511059 |
|
|
| 8 |
CAM5331 - Adaptor-oil filter
|
|
|
8,26 |
| 9 |
LYB100510 - Plug-taper thread
|
|
|
0,96 |
| 10 |
LVH10010 - Gasket-cylinder block to
oil filter adaptor
superceeded by
LVH10010B
|
|
|
0,82 |
| 11 |
FS106201 - Screw-flanged head - M6
x 20
|
|
|
0,31 |
| 12 |
LPW100180 or CDU1268
or LPW100180L or LPW100230
- Cartridge-engine oil filter
- 13/16-16UN thread (M20x1,5)
- dia=76mm H=93-100mm
options:
AHU2880
FRAM PH6811
PUROLATOR L17819 /R327
UNIPART GFE26 or GFE280 or GFE171
KNECHT-MAHLE OC237/1
MANN W713/15
MANN W713/28
Baldwins B1447
RYCO Z585
Hengst H90W29
Purflux LS802
Tecnocar R600
|
|
|
7,0 |
| 13 |
LQB100070 - Filler assembly-upper oil
|
|
|
18,95 |
| 14 |
LQC100270 - Cap-oil filler - Yellow
|
|
|
2,86 |
| 15 |
LUD100040 - Seal-engine oil filler
cap - 43mm, outside diameter
|
|
|
2,25 |
| 16 |
LQU100340 - Bracket-oil filler tube
|
|
|
1,81 |
| 17 |
FS106125 - Screw-flanged head - M6
x 12
|
|
|
0,39 |
| 18 |
FS108255 - Screw-flanged head - M8 |
|
|
0,38 |
| 18 |
FS108165 - Screw-flanged head - M8
x 16
VVC ?? |
|
|
0,39 |
| 19 |
LQZ100030 - Spacer-manifold to oil
filler bracket
superceeded by
LQZ100050
|
|
|
0,71 |
| 20 |
LQB100130 - Filler assembly-lower oil
superceeded by
LQB100150 |
|
|
|
| 20 |
LQB100150 - Filler assembly-lower oil
|
|
|
40,58 |
| 21 |
LVJ100140 - Gasket-crankcase to dipstick
tube
|
|
|
0,67 |
| 22 |
FS106125M - Screw
|
|
|
0,38 |
| 23 |
LYP000320 - Screw-flanged head - M10
x 16
|
|
|
0,39 |
| 24 |
LQM100640 - Dipstick-oil
|
|
|
4,50 |
| 903 |
LZN100220 - Insert-press in
(pipe to plastic body)
|
|
|
4,38 |
