EPC

MG Cars | MGF - MG TF | Axles, Suspension, Drive Shafts, Wheels | Front Suspension | Front Upper Arm-MGF

Parts
P/N, description, qty needed. from to
GBP
1 RBG000020 - Kit-ball joint - upper MGF front and rear suspension
GSJ269 NAM5308
QH QSJ1060S
TRW JBJ664

Cone 13mm
Thread: M34x1,5
1 13/16" nut size (46mm)
  2D600100 16,04
2 NAM2470 - Washer-lock
  2D600100 0,37
3 RDB10001 - Washer-tab upper ball joint
  2D600100 0,42
4 ADU3882 - Nut-hexagonal
M12x1 ?

Notice thread size at GSJ269 is different to the latest QSJ1060S (M12 x 1,25mm)
  2D600100 1,15
5 RBJ101210 - Arm-front&rear Suspension upper - LH
  2D600100 66,27
5 RBJ101200 - Arm-front&rear Suspension upper - RH
  2D600100 66,27
6 88G302 - Bearing
-needle roller
  2D600100 20,65
7 LN10081 - Nipple-grease
(get another with 45° angle for easier service)
  2D600100 0,39
8 2A4325 - Shaft-upper support arm
  YD532349 40,23
8 RBR000020 - Shaft-upper support arm
YD532350   40,23
9 FAM7789 - Collar
    2,63
10 2A7324 - Washer-thrust - outer
superceeded by
RDB000010
    3,75
11 2A7327 - Seal
    0,18
11 RYX000030 - Seal
    0,08
12 FAM9267 - Washer
-sealing - outer
    4,17
13 NV608041 - Nut
    1,09
14 2A4327 - Plate
    6,56
15 FS106161 - Screw-flanged head
- M6 x 16
superceeded by
FS106167

15 FS106167 - Screw
-flanged head
- M6 x 16
    0,38
16 WA112081 - Washer
-plain - M12
    0,38
17 FX106041 - Nut
- M6
    0,39
18 RYP10001 - Screw
plate to tower
    0,73
[ back ]
[ ]
[ ]
notice: parts prices are historic. Edition app. 2003. Today you pay about double and more for some of the rare parts
