P/N, description, qty needed. |
from |
to |
GBP
|
| 1 |
BMD460010 - Trunk lid assembly
MGF
- except Trophy
|
|
2D600100 |
390,58 |
| 1 |
BMD460010 - Trunk lid assembly
MGF
- Trophy
|
|
2D600100 |
342,15 |
| 1 |
BMD460070 - Trunk lid assembly
- MGTF
|
2D600101 |
|
297,65 |
| 2 |
MB460030 - Hinge assembly-trunk lid
- LH
- except Trophy
- MGTF
|
|
|
39,76 |
| 2 |
MB460090 - Hinge assembly-trunk lid
- LH
- Trophy
|
|
2D600100 |
35,72 |
| 2 |
BMB460020 - Hinge assembly-trunk lid
- RH
- except Trophy
- MGTF
|
2D600101 |
|
39,76 |
| 2 |
BMB460080 - Hinge assembly-trunk lid
- RH
- Trophy
|
2D600101 |
|
35,72 |
| 3 |
FS106167 - Screw-flanged head - M6
x 16
4 of
|
|
|
0,38 |
| 4 |
CJE100431 - Seal-trunk lid stowage
bin
|
|
|
26,04 |
| 5 |
CJE100450 - Seal-trunk lid engine
|
|
|
8,80 |
| 6 |
HYV10002 - Circlip
2 of
|
|
|
0,36 |
| 7 |
BMI460010 - Stop-trunk lid hinge
2 of
|
|
NLA |
0,69 |
| 7 |
BMI460011 - Stop-trunk lid hinge
2 of
|
|
|
1,13 |
| 8 |
AAU5486A - Buffer
2 of
|
|
|
1,02 |
| 9 |
FQU100230 - Latch-trunk lid
|
|
4D639633 |
19,39 |
| 9 |
FQR000100 - Latch-trunk lid
|
4D639634 |
|
|
| 10 |
FS106107 - Screw-flanged head
- M6 x 10
2 of
|
|
|
0,35 |
| 11 |
FQW10009PMA - Cover-trunk lid latch
- Black
superceeded by
FQW000040PMA
|
|
4D632752 |
0,74 |
| 11 |
FQW000040PMA - Cover-trunk lid latch
- Black
|
4D632753 |
|
0,74 |
| 12 |
CLP6458 - Striker
-trunk lid
|
|
|
3,08 |
| 13 |
tCLP5229 - Screw
2 of
|
|
|
0,7 |
| 14 |
CWC101920 - Lock assembly
-trunk lid
- non-specific key number
|
|
|
45,11 |
| 14 |
CWC101920H - Lock assembly
-trunk lid
- specific key number
|
|
|
75,19 |
| 15 |
FRC100090 - Cable
-trunk/tailgate lock/latch link
|
|
|
5,34 |
| 16 |
CWH100100 - Clip-lock retaining
|
|
|
3,84 |
| 17 |
FN106047 - Nut-flange
- M6
6 of
|
|
|
0,36 |
| 18 |
EYG10004 - Bolt-washer
2 of
|
|
|
0,45 |
| 19 |
WA108057 - Washer-plain
2 of
|
|
|
0,31 |
| 20 |
FQR10008 - Buffer-trunk lid
2 of
superceeded by
CZU000070
|
|
|
1,01 |
| 21 |
EZF100140 - Pad - anti rattle
|
2D600101 |
|
1,13 |
| 900 |
AVY000010 - Shedder
- trunk lid lock
|
2D600101 |
|
15,36 |
| 901 |
14A7090A rubber plug 4 of 3/4" to the 4
holes in the boot lid
Stopfen Gummi , 3/4" |
from 1998 on |
|
|
901
