P/N, description, qty needed. |
from VIN |
to VIN |
GBP |
| 1 |
ETL100201 - Pad-front footwell insulation
- RH
superceeded by
ETL100202
|
|
XD511058 |
15,07 |
| 1 |
ETL100211 - Pad-front footwell insulation
- LH
superceeded by
ETL100212
|
|
XD511058 |
15,07 |
| 1 |
ETL100202 - Pad-front footwell insulation
- RH
|
YD511059 |
|
14,52 |
| 1 |
ETL100212 - Pad-front footwell insulation
- LH
|
YD511059 |
|
14,52 |
| 2 |
ETQ100121 - Pad-rear floor insulation
|
|
|
5,32 |
| 4 |
ETC100671 - Pad-front bulkhead insulation
- lower
superceed by
ETC100672
|
|
YD516910 |
9,73 |
| 4 |
ETC100672 - Pad-front bulkhead insulation
dash lower
|
YD516911 |
|
9,73 |
| 5 |
ETU100150 - Pad-rear bulkhead insulation
|
|
2D535184 |
31,42 |
| 5 |
ETU000050 - Pad-rear bulkhead insulation
|
2D535185 |
|
31,12 |
| 6 |
ETC100820 - Pad-insulation engine bay
superceeded by
ETC107130
|
|
YD519804 |
30,12 |
| 6 |
ETC107130 - Pad-insulation engine bay
1800 ccm - |
YD519805 |
2D600100 |
31,42 |
| 6 |
ETC000410 - Pad-insulation engine bay
|
2D600101 |
|
28,41 |
| 7 |
ETC100840 - Pad-insulation engine bay
- LH
VVC - |
|
YD522572 |
21,98 |
| 7 |
ETC100850 - Pad-insulation engine bay
- RH
|
|
YD522572 |
21,98 |
| 8 |
ETU100171 - Pad-hoodwell insulation
|
|
YD517025 |
35,53 |
| 8 |
ETU100470 - Pad-hoodwell insulation
superceeded by
ETU000070
(REPLACES BOTH ETU100470 AND ETU105520)
|
YD517026 |
2D604406 |
34,25 |
| 8 |
ETU105520 - Pad-hoodwell insulation
Heavy layer
ETU000070
(REPLACES BOTH ETU100470 AND ETU105520)
|
YD517026 |
2D604406 |
34,25 |
| 8 |
ETU000070 - Pad-hoodwell insulation
|
2D604407 |
|
32,31 |
| 9 |
EYC101040 - Clip
|
|
YD519804 |
|
| 10 |
EYC10061 - Clip - female
NVH to rear bulkhead
|
|
|
|
| 11 |
EUM10001 - Clip - male
NVH to rear bulkhead
|
|
|
0,40 |
| 11 |
EUM10001 - Clip - male
NVH to rear bulkhead (10)
|
YD519805 |
|
0,40 |
| 12 |
ETC100830 - Pad-fuel bay bulkhead insulation
|
|
|
23,09 |
| 13 |
EYC101050 - Clip-trim retention
|
|
|
|
| 14 |
ETR100090 - Pad-tunnel insulation -
LH, upper
|
|
|
2,16 |
| 14 |
ETR100080 - Pad-tunnel insulation -
RH, upper
|
|
|
2,16 |
| 15 |
EYG100140 - Bolt-torx-pan
insulation to engine bay
|
|
|
0,38 |
| 16 |
DCP4229 - Scrivet
engine bay insulation to subframe
superceeded by
KYC100020
Schraubniet
use Sciffy 113108059902
or Ettinger 72.11.880
|
|
|
|
| 900 |
AJU1136 - Stud
hoodwell pads
|
YD517026 |
|
|
