P/N, description, qty needed. |
from |
to |
GBP |
| 1 |
TBB100760 - Differential assembly |
|
|
|
| 2 |
tTBF100080 - Case differential |
|
|
|
| 3 |
TBN100010 - Shaft-pinion differential |
|
|
|
| 4 |
TCB100260 - Gear differential |
|
|
|
| 5 |
TCC100120 - Pinion-differential-side
transmission |
|
|
|
| 6 |
DBM739 - Washer-thrust |
|
|
|
| 7 |
TYT100090 - Pin |
|
|
|
| 8 |
DBM733 - Washer-thrust - .80mm, "c" |
|
|
|
| 8 |
DBM734 - Washer-thrust - .85mm, "d" |
|
|
|
| 8 |
DBM735 - Washer-thrust - .90mm, "e" |
|
|
|
| 8 |
DBM736 - Washer-thrust - .95mm, "f" |
|
|
|
| 8 |
DBM738 - Washer-thrust - 1.05mm, "h" |
|
|
|
| 8 |
DBM737 - Washer-thrust - 1.0mm, "g" |
|
|
|
| 8 |
DBM731 - Washer-thrust - "a",
.70mm |
|
|
|
| 8 |
DBM732 - Washer-thrust - "b",
.75mm |
|
|
|
| 9 |
TXF100090 - Gear-speedometer drive
- plastic, 23 teeth
- 1800 ccm |
|
|
|
| 10 |
CDU85 - Bearing-ball differential |
|
|
|
| 11 |
tDBM709 - Gear-final drive differential
- 63 teeth
C6 -
Trophy VVC - |
|
|
|
| 11 |
DBM709 - Gear-final drive differential
- 63 teeth
C6 -
Trophy VVC - |
|
|
|
| 11 |
DBM711 - Gear-final drive differential
- single groove, 63 teeth, K4BX
VVC - C4 - |
|
|
|
| 11 |
DBM711 - Gear-final drive differential
- single groove, 63 teeth, K4BX
VVC - C4 - |
|
|
|
| 12 |
DBM740 - Bolt differential
- 1800 ccm |
|
|
|
| 13 |
DBM741 - Ring-snap - "1",
2.50mm |
|
|
|
| 13 |
DBM742 - Ring-snap - "2",
2.60mm |
|
|
|
| 13 |
DBM743 - Ring-snap - "3",
2.70mm |
|
|
|
| 13 |
DBM746 - Ring-snap - 3.00mm, "6" |
|
|
|
| 13 |
DBM744 - Ring-snap - "4",
2.80mm
- 1800 ccm |
|
|
|
| 13 |
DBM745 - Ring-snap - "5",
2.90mm |
|
|
|
