P/N, description,
qty needed. |
from |
to |
GBP |
| 1 |
CUB102330 - Glass assembly-front door
tinted - LH, Green
|
|
AD002965 |
NLA |
| 1 |
CUB102331 - Glass assembly-front door
tinted - LH, Green
superceeded by
CUB102610
superceeded by
CUB103260
|
AD002966 |
AD016443 |
|
| 1 |
CUB102610 - Glass assembly-front door
tinted - LH, Green
superceeded by
CUB103260
|
AD016444 |
WD037077 |
|
| 1 |
CUB103260 - Glass assembly-front door
tinted - LH, Green
|
WD037078 |
XD040561 |
104,53 |
| 1 |
CUB102930 - Glass assembly-front door
tinted - LH
superceeded by
CUB103710
superceeded by
CUB000450
|
XD 40562 |
YD517151 |
|
| 1 |
CUB103710 - Glass assembly-front door
tinted - LH
superceeded by
CUB000450
|
YD517152 |
4D620878 |
|
| 1 |
CUB000450 - Glass assembly-front door
tinted - LH, Lead Free, Front door tinted
|
4D620879 |
|
104,53 |
| 1 |
CUB102320 - Glass assembly-front door
tinted - RH, Green
superceeded by
CUB102600
superceeded by
CUB103250
superceeded by
CUB102920
superceeded by
CUB103700
superceeded by
CUB000440
|
|
AD002965 |
NLA |
| 1 |
CUB102321 - Glass assembly-front door
tinted - RH, Green
superceeded by
CUB102600
superceeded by
CUB103250
superceeded by
CUB102920
superceeded by
CUB103700
superceeded by
CUB000440
|
AD002966 |
AD016443 |
|
| 1 |
CUB102600 - Glass assembly-front door
tinted - RH, Green
superceeded by
CUB103250
superceeded by
CUB102920
superceeded by
CUB103700
superceeded by
CUB000440
|
AD016444 |
WD037077 |
|
| 1 |
CUB103250 - Glass assembly-front door
tinted - RH, Green
CUB102920
superceeded by
CUB103700
superceeded by
CUB000440
|
WD037078 |
XD040561 |
|
| 1 |
CUB102920 - Glass assembly-front door
tinted - RH
superceeded by
CUB103700
superceeded by
CUB000440
|
XD040562 |
YD517151 |
|
| 1 |
CUB103700 - Glass assembly-front door
tinted - RH
superceeded by
CUB000440
|
YD517152 |
4D620878 |
|
| 1 |
CUB000440 - Glass assembly-front door
tinted - RH, Lead Free
|
4D620879 |
|
104,53 |
| 2 |
CVI100030 - Lift assembly-front door
glass - LH
|
|
|
124,84 |
| 2 |
CVI100020 - Lift assembly-front door
glass - RH
|
|
|
124,84 |
| 3 |
CXV100010 - Sleeve-front door sash
adjuster
|
|
|
1,76 |
| 4 |
CVT100061 - Screw & washer assembly-glass
lift module
superceeded by
CVT100080
superceeded by
CVT100081 plus
CYF000060 Washer
|
|
WD030153 |
|
| 4 |
CVT100080 - Screw & washer assembly-glass
lift module
superceeded by
CVT100081 plus
CYF000060 Washer
|
WD030154 |
3D618503 |
|
| 4 |
CVT100081 - Screw & washer assembly-glass
lift module
|
3D0618504 |
|
2,62 |
| 5 |
CUN100390 - Bracket-front door glass
stop
2 of
|
|
|
1,86 |
| 6 |
FN108047 - Nut-flange - M8
superceeded by
FN108041
|
|
|
0,35 |
| 7 |
FN106047 - Nut-flange - M6
2 of
|
|
|
0,35 |
| 8 |
CUQ100101 - Stopper-door glass (white
plastic)
This is crap !!
Replace with #9
|
|
AD016433 |
x |
| 8 |
CUQ100102 - Stopper-door glass (amber
plastic)
This is crap !!
Replace with #9
|
AD016434 |
WD037077 |
x |
| 9 |
CUQ100140 - Stopper-door
glass
|
WD037078 |
|
2,08 |
| 10 |
CVT100090 - Washer-glass
lift stop assembly
|
WD037078 |
|
0,69 |
| 11 |
SS105161 - Screw-hexagon
socket - M5 x 16 -- glass stop to door glass
|
WD037078 |
|
0,48 |
| 12 |
CLP2879 - Sems-hexagonal socket - M6
4 of
|
|
|
0,30 |
| 13 |
CXW100020 - Bolt-shouldered-glass retention
2 of
|
|
|
0,31 |
| 14 |
CFE101870 - Seal assembly-front door
cheater - LH
superceeded by
CFE101871
superceeded by
CFE102870
superceeded by
CFE103030
|
|
AD007718 |
|
| 14 |
CFE101871 - Seal assembly-front door
cheater - LH
superceeded by
CFE102870
superceeded
superceeded by
CFE103030
|
AD007719 |
WD031660 |
|
| 14 |
CFE102870 - Seal assembly-front door
cheater - LH
superceeded by
CFE103030
|
WD031661 |
XD511058 |
|
| 14 |
CFE103030 - Seal assembly-front door
cheater - LH
|
YD511059 |
|
43,68 |
| 14 |
CFE101860 - Seal assembly-front door
cheater - RH
superceeded by
CFE101861
superceeded by
CFE102900
superceeded by
CFE103020
|
|
AD007718 |
|
| 14 |
CFE101861 - Seal assembly-front door
cheater - RH
superceeded by
CFE102900
superceeded by
CFE103020
|
AD007719 |
WD031660 |
|
| 14 |
CFE102900 - Seal assembly-front door
cheater - RH
superceeded by
CFE103020
|
WD031661 |
XD511058 |
|
| 14 |
CFE103020 - Seal assembly-front door
cheater - RH
|
YD511059 |
|
43,68 |
| 15 |
CYP100690 - Sems-dog point - patch
lock
|
XD041457 |
|
0,55 |
| 16 |
BNP4107PA - Clip-plastic - Black
cheater to body
superseeded by
BNP4107PMA Clip -
Black (see door seals)
|
|
XD507676 |
1,26 |
| 16 |
CYC100550 - Clip-plastic - Black
cheater to body
|
XD507677 |
|
0,48 |
| 17 |
CVW100150 - Waistrail-front door outer
- LH
superseeded by
CFE101871
superseeded by
CFE102870
superseeded
CFE103030 front door cheater
LH
|
|
AD007718 |
3,45 |
| 17 |
CVW100140 - Waistrail-front door outer
- RH
superseeded by
CFE101861
superseeded by
CFE102900
superseeded by
CFE103020 front door
cheater RH
|
|
AD007718 |
3,62 |
| 18 |
SF104121 - Screw
4 of
|
|
|
0,32 |
| 19 |
CUH102150 - Regulator assembly-front
door electric glass - LH
|
|
WD030081 |
178,18 |
| 19 |
CUH102250 - Regulator assembly-front
door electric glass - LH
superseeded by
CUH000410
|
WD030082 |
4D631732 |
153,67 |
| 19 |
CUH000410 - Regulator assembly-front
door electric glass - LH
|
4D631733 |
|
169,03 |
| 19 |
CUH102140 - Regulator assembly-front
door electric glass - RH
|
|
WD030081 |
173,18 |
| 19 |
CUH102240 - Regulator assembly-front
door electric glass - RH
|
WD030082 |
4D631732 |
149,56 |
| 19 |
CUH000400 - Regulator assembly-front
door electric glass - RH
|
4D631733 |
|
169,03 |
| 20 |
FS106121P - Screw - patch lock
4 of
|
|
|
1,36 |
| 21 |
CYF000060 - Washer
|
3D615388 |
|
0,24 |
